Steel decks, made of corrugated steel sheets, are versatile structural components used to support roofs, floors, or as composite decks. As roof decks, they provide support for roofing materials such as insulation and waterproofing layers, while also serving as a diaphragm to enhance the structural stability of the building. As floor decks, they can either be used as permanent formwork for concrete slabs or as composite decks that bond with concrete, increasing overall strength and reducing the need for additional reinforcement.
Detailing of steel decks involves preparing precise layouts that show how the panels will be installed, ensuring proper orientation and alignment with the structural framework. It also includes specifying the type and profile of the steel deck, as well as providing detailed instructions for attachment to the supporting structure, whether through welding, fastening, and/or screw patterns.
At Ridge Steel Works, our experienced team is well-versed in the detailing of various types of decks.
We Offer Specialized Services For
Roof
Decks
Composite
Decks
Form
Decks
Cellular
Decks
Reveal Series
and Dovetail Decks
Key Considerations
The following key considerations are essential for detailing steel decks:
- Deck Type: The specific deck profile is determined by rib height and spacing, which are essential for evaluating the deck’s structural capacity.
- Deck Span: Appropriate span lengths are calculated based on load requirements, joist spacing, and deck type. Larger spans typically necessitate deeper profiles or additional reinforcement.
- Material Specifications: The appropriate steel grade is specified according to structural requirements.
- Coatings and Finishes: Necessary coatings, such as galvanized finishes for corrosion resistance and primers for aesthetics or protection, are detailed.
- Composite Action: For composite decks, shear studs and their spacing are specified to connect the steel deck to the concrete slab, allowing them to function as a unified structural element.
- Deflection Limits: Deflection is monitored to ensure it remains within acceptable tolerances, preventing cracking or sagging in floor deck.
- Shear Forces: The deck’s ability to effectively transfer shear forces is evaluated, ensuring structural integrity.
